Battery Tester Solar TOOLTOP Battery Internal Resistance Tester, 4 Wire Kelvin Test, Lead Acid Lithium Nickel Cadmium Battery Tool, IR502 ±120V 500Ω
- Order Processing Time: Within 24hrs
- Ships In: 3-5 Working Days
- Courier Service: Sonic Trax / Leopard
- Return: Return unused items within 7 days
- Quality as Promised: Trusted Since 1965, quality and customer satisfaction have been our commitment.
Features
Battery Selection criteria: Lead Acid Battery, Lithium Battery, Nickel Cadmium Battery, Alkaline Battery, etc....
Voltage: 0.00V to ±120V
Internal Resistance measurement: 0.000mΩ to 500Ω
Maximum input Voltage: DC120V (non-polarized), no AC input
Measurement Current: 50mA ~ 50uAAC
Measurement Speed: 3 times/sec
Signal Frequency measurement: 1KHz
Voltage Range selection: Automatic/Manual selection
Internal Resistance Range selection: automatic/manual selection
Autonomous Connectivity options: YES
Measurement method: 4-line Kelvin test method
User self-calibration: YES
Autonomous Factory Recovery: YES
Battery Selection criteria: Lead Acid Battery, Lithium Battery, Nickel Cadmium Battery, Alkaline Battery, etc.
Screen and size: 55*57mm TN black and white screen (IR500)
55*57mm VA color screen (IR502)
Power supply: 3.7V lithium battery
Lighting function: YES
Other features: Low Voltage Detection, White Backlight, Automatic Shutdown
Package List:
1 x IR502 Battery Tester
1 x Charging Cable
1 x storage cloth bag
1 x Color Package Box
